class: center, middle, inverse, title-slide # GCTA ## a tool for Genome-wide Complex Trait Analysis ### 王　超辰 ### 2017/5/16 --- class: center, middle # BACKGROUND --- class: center, middle .pull-left[ **Mendelian Traits**<br>_Sickle-cell disease_(鎌状赤血球病)  ] .pull-right[ **Complex traits**<br> _Human height_(身長)  <br> _Schizophrenia_(統合失調症)  ] --- # Major Questions <br> - ### **Are these traits heritable ?** - ### **If so, what is the heritability ?** - ### **How many genes involved and where are they located ?** --- ## Complex traits such as height, BMI and SCZ are highly heritable _according to twins studies._ - ### Human Height : `\(\sim 80\%\)` - ### Body mass index : `\(40\% \sim 60\%\)` - ### Schizophrenia : `\(\sim 80\%\)` --- ## The missing heritability problem .pull-left[ #### Height: - 180 loci - `\(\sim\)` 180K samples - `\(<\)` 10 `\(\%\)` of variance explained - heritablity = `\(\sim\)` 80 `\(\%\)` #### BMI: - 32 loci - `\(\sim\)` 250K samples - `\(\sim\)` 1 `\(\%\)` of variance explained ] .pull-right[ #### Schizophrenia - 22 loci - `\(\sim\)` 21K cases/ `\(\sim\)` 38K controls - `\(<\)` 3 `\(\%\)` of variance explained #### Possible reasons: - Effect sizes at individual SNPs are **too small to reach** `\(5 \times 10^{-8}\)` - Causal variants are **not in sufficient LD** with SNPs on the commercial arrays to be detected. ] --- class: middle, center background-image: url(fig/missingheri.png) background-size: contain --- ## Estimating the Variance Explained by Genome-Wide SNPs ### Basic concept: - To fit all the SNPs simultaneously as **random effects** in a mixed linear model. - To estimate **the variance explained by all the SNPs** without testing for associations of any individual SNP with the trait. --- class: inverse, center, middle # GCTA models --- ## Model (1) `$$y = Xb + Wu + e \\ with\\ var(y)=V=WW^{\prime}\sigma_u^2+I\sigma_e^2 \;\;(1)$$` - `\(y\)` is a `\(n \times 1\)` vector of phenotypes(身長，BMI，糖尿病ありなしetc.);<br> `\(n =\)` sample size; - `\(b\)` is a vector of fixed covariates. - `\(u\)` is a vector of **SNP effects** with `\(u \sim N(0, I\sigma_u^2)\)` - `\(I\)` is a `\(n \times n\)` identity matrix (単位行列) - `\(e\)` is a vector of residual effects with `\(e \sim N(0, I\sigma_e^2)\)` - `\(W\)` is a standardized SNP genotype matrix with the `\(ij\)`th element `\(w_{ij}=\frac{(x_{ij}-2p_i)}{\sqrt{2p_i(1-p_i)}}\)`, where `\(x_{ij}\)` is the number of copies of the reference allele for the `\(i\)`th SNP of the `\(j\)`th individual and `\(p_i\)` is the frequency of the reference allele of SNP `\(i\)`. --- ## Model (2) #### Define `\(A=\frac{WW^{\prime}}{N}\)` #### Define `\(\sigma_G^2\)` as the variance explained by all the SNPs i.e., <br> `\(\sigma_G^2 = N\sigma_u^2\)` with `\(N=\)` number of SNPs. #### Equation (1) `$$y = Xb + Wu + e \\ with\\ var(y)=V=WW^{\prime}\sigma_u^2+I\sigma_e^2 \;\;(1)$$` #### is equivalent to equation (2) `$$y = Xb + g + \epsilon \\ with \\ var(y)=V=A\sigma_G^2+I\sigma_e^2 \;\;(2)$$` --- class: middle ## Equation (2) ### `$$y = Xb + g + \epsilon \\ with \\ var(y)=V=A\sigma_G^2+I\sigma_e^2 \;\;(2)$$` - `\(g\)` is a `\(n \times 1\)` vector of the total additive genetic effects of the individuals with `\(g\sim N(0, A\sigma_G^2)\)` - `\(A=\)` **genetic relationship matrix (GRM)** between individuals with the `\(kj\)`th element being `\(A_{kj}=\frac{1}{N}\sum_{i-1}^N\frac{(x_{ij}-2p_i)(x_{ik}-2p_i)}{2p_i(1-p_i)}\)` - `\(\sigma_G^2\)` and `\(\sigma_e^2\)` can be estimated by restricted maximum likelihood (REML) approach. --- ### `\(h_{SNP}^2\)` - **Define** `\(h_{SNP}^2=\frac{\sigma_G^2}{(\sigma_G^2+\sigma_e^2)}\)` as the **proportion of phenotypic variance explained by all the SNPs**; - `\(h_{SNP}^2\)` is **directly comparable** to the results from GWAS analyses. - **For Example, Human Height:** - `\(\sim 10\%\)` of variance explained by `\(180\)` genome-wide significant SNPs `\((p<5\times 10^{-8})\)`^[1]; - `\(h_{SNP}^2=0.45 (s.e.=0.08)\)`, meaning all common SNPs explain `\(\sim 45\%\)` of the phenotypic variance^[2] - Distinction needed: `\(h_{SNP}^2\neq (h^2) heritability\)` - current generation of genotyping arrays are unlikely to perfectly tag all causal variants for a trait; - `\(h_{SNP}^2\)` from unrelated individuals is **an unbiased estimate of `\(h^2\)`**. .footnote[ [1] Lango Allen, et al. (2010). Hundreds of variants clustered in genomic loci and biological pathways affect human height. Nature 467, 832–838. [2] Yang, J., et al. (2010). Common SNPs explain a large proportion of the heritability for human height. Nat. Genet. 42, 565–569. ] --- ## [GCTA applications: (1)](http://cnsgenomics.com/software/gcta/index.html) * #### Step 1: generating **genetic relationship matrix (GRM)**<br> + a GWAS dataset in PLINK binary PED format (`test.bed; test.bim; test.fam`) + _Command 1_: ```yaml ./gcta64 --bfile test --autosome --make-grm --out test ``` + _Command 2_: GRM for each chromosome (large dataset) ```yaml ./gcta64 --bfile test --chr1 --make-grm --out test_chr1 ./gcta64 --bfile test --chr2 --make-grm --out test_chr2 ... ./gcta64 --bfile test --chr22 --make-grm --out test_chr22 ``` + and then merge all the GRMs by _command 3_: ```yaml ./gcta64 --mgrm grm_chrs.txt --make-grm --out test ``` --- ## [GCTA applications: (2)](http://cnsgenomics.com/software/gcta/index.html) * #### Step 2: estimate the variance explained by all SNPs by a Restricted Maximum Likelihood (REML) analysis of the phenotypes with the GRM. + _Command 4_: ```yaml ./gcta64 --grm test --pheno test.phen --reml --out test ``` `sleep.phen:` <div id="htmlwidget-a3e2cd9b2879530936b5" style="width:100%;height:auto;" class="datatables html-widget"></div> <script type="application/json" data-for="htmlwidget-a3e2cd9b2879530936b5">{"x":{"filter":"none","fillContainer":false,"data":[["1","2","3","4","5","6","7","8","9","10"],["jmicc000001","jmicc000002","jmicc000003","jmicc000004","jmicc000005","jmicc000006","jmicc000007","jmicc000008","jmicc000009","jmicc000010"],["jmicc000001","jmicc000002","jmicc000003","jmicc000004","jmicc000005","jmicc000006","jmicc000007","jmicc000008","jmicc000009","jmicc000010"],["6.5","8","5","6","6.5","6","6.5","8","7","6.5"]],"container":"<table class=\"display\">\n <thead>\n <tr>\n <th> <\/th>\n <th>ID<\/th>\n <th>ID.1<\/th>\n <th>SleepTime<\/th>\n <\/tr>\n <\/thead>\n<\/table>","options":{"pageLength":3,"order":[],"autoWidth":false,"orderClasses":false,"columnDefs":[{"orderable":false,"targets":0}],"lengthMenu":[3,10,25,50,100]}},"evals":[],"jsHooks":[]}</script> --- ```yaml ./gcta64 --reml --grm-bin JMICC --pheno sleep.phen --out sleep ****************************************************************** Genome-wide Complex Trait Analysis (GCTA) version 1.26.0 (C) 2010-2016, The University of Queensland MIT License Please report bugs to: Jian Yang <jian.yang@uq.edu.au> ******************************************************************* Analysis started: Sat May 13 17:50:51 2017 Options: --reml --grm-bin JMICC --pheno sleep.phen --out sleep Note: This is a multi-thread program. You could specify the number of threads by the --thread-num option to speed up the computation if there are multiple processors in your machine. Reading IDs of the GRM from [JMICC.grm.id]. 14088 IDs read from [JMICC.grm.id]. Reading the GRM from [JMICC.grm.bin]. GRM for 14088 individuals are included from [JMICC.grm.bin]. Reading phenotypes from [sleep.phen]. Non-missing phenotypes of 9676 individuals are included from [sleep.phen]. ``` --- background-image: url(fig/calculation.jpg) background-size: contain --- background-image: url(fig/memory.jpg) background-size: contain --- class: middle ### Common SNPs explain 23% of the heritability for sleep duration in JMICC study participants ```yaml Summary Result of REML analysis: Source Variance SE V(G) 86.516241 12.555365 V(e) 288.099351 12.738188 Vp 374.615592 5.506539 *V(G)/Vp 0.230947 0.033053 LogL -32278.958 LRT 62.124 df 1 Pval 1.61e-15 n 9326 ``` --- ## Extension: Genetic correlation between two traits > Comparing the phenotypic similarity and the genetic similarity between individuals **within** and **cross** two traits. `$$cov(y_{i1},y_{k1})=A_{ik}\sigma_{g1}^2\\var(y_{i1})=A_{ii}\sigma_{g1}^2+\sigma_{e1}^2$$` `$$cov(y_{i2},y_{k2})=A_{ik}\sigma_{g2}^2\\var(y_{i2})=A_{ii}\sigma_{g2}^2+\sigma_{e2}^2$$` `$$cov(y_{i1},y_{k2})=A_{ik}\sigma_{g1g2}\\cov(y_{i1},y_{i2})=A_{ii}\sigma_{g1g2}+\sigma_{e1e2}$$` "1" = trait 1, "2" = trait 2; `\(\sigma_{g1g2} =\)` genetic covariance; `\(\sigma_{e1e2}=\)` environmental covariance<br> `$${\bf Genetic\;correlation}\rightarrow r_g=\frac{\sigma_{g1g2}}{\sigma_{g1}\sigma_{g2}}$$` --- ### **GCTA bivariate GREML analysis application** ```yaml *./gcta64 --reml-bivar --grm JMICC --pheno sleepBMI.phen --out JMICCsleepBMI ... Analysis started: Sun Apr 23 21:55:02 2017 Options: --reml-bivar 1 2 --grm JMICC --pheno sleepBMI.phen --out JMICCsleepBMI Reading IDs of the GRM from [JMICC.grm.id]. 14088 IDs read from [JMICC.grm.id]. Reading the GRM from [JMICC.grm.bin]. GRM for 14088 individuals are included from [JMICC.grm.bin]. Reading phenotypes from [sleepBMI.phen]. There are 2 traits specified in the file [sleepBMI.phen]. Traits 1 and 2 are included in the bivariate analysis. Non-missing phenotypes of 14555 individuals are included from [sleepBMI.phen]. 13631 individuals are in common in these files. 13617 non-missing phenotypes for trait 1 and 13619 for trait 2 ``` --- class: middle ### The genetic correlation association between BMI and sleep duration ```yaml Summary result of REML analysis: Source Variance SE V(G)_tr1 5.886921 0.261958 V(G)_tr2 0.348178 0.023045 C(G)_tr12 0.041237 0.062379 V(e)_tr1 4.588593 0.212535 V(e)_tr2 0.662649 0.021347 C(e)_tr12 -0.028576 0.053324 Vp_tr1 10.475513 0.133431 Vp_tr2 1.010827 0.012377 V(G)/Vp_tr1 0.561970 0.021571 V(G)/Vp_tr2 0.344449 0.021459 *rG 0.028803 0.043606 ``` --- ### rG summary <div id="htmlwidget-afe79c5d1766ad13bb66" style="width:100%;height:auto;" class="datatables html-widget"></div> <script type="application/json" data-for="htmlwidget-afe79c5d1766ad13bb66">{"x":{"filter":"none","fillContainer":false,"data":[["1","2","3","4","5","6","7","8","9","10"],["BMI","DM (case-control) pre=0.59","CRP","Alcohol intake (now)","Drink-year","HbA1c-log","stress","tobacco","Pack-year","Fasting blood sugar-log"],[0.03,0.11,-0.14,0.22,0.23,0.01,-0.17,0.003,-0.2,0.28],[0.04,0.06,0.21,0.1,0.1,0.12,0.05,0.09,0.23,0.17],[-0.06,-0.01,-0.55,0.02,0.02,-0.24,-0.28,-0.17,-0.64,-0.05],[0.11,0.22,0.26,0.42,0.43,0.25,-0.06,0.18,0.24,0.61],[-0.005,0.042,0.031,0.099,0.124,0.002,-0.183,0.026,0.099,0.051],[-0.021,0.138,-0.008,0.077,0.107,-0.02,0.046,0.01,0.082,0.016],[0.012,0.076,0.07,0.121,0.141,0.023,-0.162,0.042,0.115,0.087]],"container":"<table class=\"display\">\n <thead>\n <tr>\n <th> <\/th>\n <th>Trait<\/th>\n <th>rG<\/th>\n <th>SE<\/th>\n <th>CI.low<\/th>\n <th>CI.high<\/th>\n <th>r<\/th>\n <th>CI.low.1<\/th>\n <th>CI.high.1<\/th>\n <\/tr>\n <\/thead>\n<\/table>","options":{"pageLength":6,"columnDefs":[{"className":"dt-right","targets":[2,3,4,5,6,7,8]},{"orderable":false,"targets":0}],"order":[],"autoWidth":false,"orderClasses":false,"lengthMenu":[6,10,25,50,100]}},"evals":[],"jsHooks":[]}</script> --- class: middle ### Correlation between two variables (both genetic and phenotypic correlation) in JMICC study <br> upper right: rG; <br> lower left: r <table border='3' cellpadding='6' align="center" style="margin: 0px auto;"> <tr> <th> Traits </th> <th> Alcohol </th> <th> Stress </th> <th> Education </th> <th> SBP </th> </tr> <tr> <th> Alchol </th> <td align="center"> － </td> <td align="center"> -0.13 <br> (-0.32, 0.07) </td> <td align="center"> -0.11 <br> (-0.28, 0.06) </td> <th align="center"> 0.27 <br> (0.12, 0.43) </th> </tr> <tr> <th> Stress </th> <td align="center"> -0.06 <br> (-0.08, -0.03) </td> <td align="center"> － </td> <th align="center"> 0.42 <br> (0.14, 0.71) </th> <td align="center"> -0.23 <br> (-0.48, 0.02) </td> </tr> <tr> <th> Education </th> <td align="center"> 0.10 <br> (0.07, 0.12) </td> <td align="center"> 0.03 <br> (0.00, 0.07) </td> <td align="center"> － </td> <td align="center"> -0.13 <br>(-0.32, 0.07) </td> </tr> <tr> <th> SBP </th> <td align="center"> 0.19 <br>(0.17, 0.21) </td> <td align="center"> -0.14<br> (-0.17, -0.11) </td> <td align="center"> -0.02<br> (-0.06, 0.01) </td> <td align="center"> － </td> </tr> </table> --- class: middle, center background-image: url(fig/discussion.png) background-size: contain --- class: center, middle, inverse background-image: url(fig/dna.jpg) background-size: cover # Thanks!
